Wall Mounted Garden Frame for 140x140 Posts

Brackets Precision Crafted for 140x140mm Timber Fit
Weather-resistant & rust protective coating
Laser-cut, folded and internally welded for premium quality finish
10-year Warranty on Steel

4 x L-Brackets for 140x140 Posts

4 x Wall Mounting Brackets for 140x140 Posts

64 x 12g/38mm Black Plated Fastening Screws to fasten your brackets securely to the timber.

L-Bracket Measurements:
Arm Opening Designed for 140x140mm timber fit
Arm Opening (Interior): 143 x 143mm
Arm Opening (Exterior): 149 x 149mm
Arm Length: 230 mm
Steel Thickness: 3mm
Bracket Dimensions (L x W x H): 230 x 149 x 230mm
Colour: Black (Powder Coated)
Six Fastening Holes: 7mm

Wall Mounting Bracket:
Arm Opening Designed for 140x140mm timber fit
Arm Opening (Interior): 143 x 143mm
Arm Opening (Exterior): 149 x 149mm
Arm length: 230 mm
Steel Thickness: 3mm
Base dimensions: 220 x 220mm
Colour: Black (Powder Coated)
Six Fastening Holes: 7mm
Anchoring Holes: 12mm

4 x Two Arm L Brackets:
Weather-resistant and protective coating
Laser-cut, folded and internally welded for slick quality finish
5-year limited warranty

Inclusions:
64 x 12G 38mm screws

At this time, we do not offer anchoring hardware with our brackets. This is because various flooring types such as concrete, brick or timber decking require different screws or bolts. However, anchoring hardware is easily accessible at your local hardware store who can also advise you on what fits best for your flooring.

We also do not provide the timber as we offer you the freedom to customise your pergola to the size and timber type that fits best with your space. Timber is also more affordable to source from your local timber warehouse.

Although our brackets are designed for a 140x140mm timber fit, we recommend you take your bracket to your timber warehouse to confirm fit before purchasing the posts for your pergola.

We will be happy to assist you with any return and exchange of our products in accordance with our return and exchange policies.
